With more and more industries using UVLED curing machines, Height-LED often encounters some customers who are just beginning to understand or use UVLED curing machines. These customers who have come into contact with UVLED curing machines for the first time will feel unfamiliar with some common terms and units of UVLED curing machines, and they will not know how to start, and they will also have some inconvenience when communicating with UVLED curing machine manufacturers.

As a UVLED curing machine manufacturer, Height-LED has more than ten years of R&D and production experience in the field of UVLED curing. Today, I will share with you some common terms and units in the UVLED industry, hoping to help friends who are new to UVLED curing machines. .

Introduction to common terms and units of UVLED curing machine

1. Luminous flux φ: the sum of the amount of light emitted by the luminous body per second. Unit: Lumen (Lm), which indicates how much the luminous body emits, the more luminous, the greater the number of lumens. The general luminous flux is used by UVLED lamp beads and chip manufacturers to measure the luminous efficiency of the lamp beads.

2. Light Intensity I: The luminous flux emitted by a luminous body within a unit solid angle in a specific direction. Unit: candela (cd).

3. Illuminance E: The luminous flux of the illuminant irradiated on the unit area of the illuminated object. Unit: Lux (Lux) = Lumen Lm/area m2. Of course, the power measurement unit is generally used in the UVLED curing machine industry: mW/cm2. The light intensity, radiance and intensity in the general industry refer to illuminance.

4. Brightness L: The luminous flux of the illuminant in a specific direction per unit solid angle and unit area. Unit: Nitre (mcd). For example, an LED with a luminous angle of 60 degrees has a luminous flux in a 60-degree cone.

5. Light efficiency: the ability of an electric light source to convert electrical energy into light, expressed by dividing the emitted luminous flux by the power consumption. Unit: lumens per watt (Lm/w). The UVLED industry is generally called the photoelectric conversion rate, and the photoelectric conversion efficiency of the UVLED curing machine is generally between 5% and 20%.

6. Lifespan: Considering the damage of the UVLED curing machine and the attenuation of the beam output at the same time, its comprehensive beam output is reduced to a specific number of hours. Generally, the initial light source is 70%.

As a manufacturer of UVLED curing equipment, Shenzhen Height-LED is committed to providing customers with a complete set of curing solutions. The products have standard products and can also customize products according to customer needs. If you have UVLED curing requirements, you can contact online customer service, or call for consultation and exchange.
